COOK® 70C15D 70C15D

COOK® 70C15DH Downblast Roof Exhaust Fan, 115/60/1, Spun Aluminum

COOK® 70C15DH Downblast Roof Exhaust Fan, 115/60/1, Spun Aluminum

Part Number: 70C15D

MPN: 70C15D

Brand: COOK®

Login for Price & Availability

Add to cart

Add to favorites
Share Email Print
  1. pin-int

COOK® 70C15D

COOK® Downblast Roof Exhaust Fan, Direct Drive, Spun Aluminum, Curb Mount, 194 CFM @ .25" wg, Motor Specs: 1/20 HP, 1550 RPM, 115/60/1

Base Size      :      18 x 18 in
CFM Rating @ .25" wg.      :      194 CFM
CFM Rating      :      171 cfm
Drive Type      :      Direct Drive
Electrical Power      :      115/60/1 volts/hertz/phase
Frequency Rating      :      60 Hz
Height      :      13-13/16 in
Installation Location      :      Roof Mounted
Material      :      Spun Aluminum
Model      :      70C15D
Motor HP      :      1/25 HP
Motor RPM      :      1550 RPM
Motor Specifications      :      1/20 hp
Mounting Type      :      Roof
Number of Speeds      :      2
Phase      :      1 ph
Power Rating      :      1/20 hp
Roof Opening      :      13-1/2 x 13-1/2 in
Series      :      ACED
Speed Rating      :      1550 rpm
Type      :      Downblast
Voltage Rating      :      115 V
Width      :      13-5/8 in
  • AC unit top cap assembly is designed to provide weather protection for the motor and drive components while maintaining easy, tool-free access for inspection and maintenance
  • Standard lifting lugs, located under the top cap, provide for safe, fast and efficient lifting of the unit to a rooftop
  • One-piece fan base, which includes a high-efficiency inlet venture and continuously welded curb cap corners, ensures weather tight conditions
  • Spun aluminum baffle is designed to provide smooth, turbulent-free airflow
  • Wheels are centrifugal type featuring non-overloading, backward inclined blades and a tapered inlet shroud
  • Accurate performance is assured through compliance with the AMCA certified
  • Fan shall be of bolted and welded construction utilizing corrosion-resistant fasteners
  • The spun aluminum structural components shall be constructed of minimum 16 ga marine alloy aluminum, bolted to a rigid aluminum support structure
  • The aluminum base shall have continuously welded curb cap corners for maximum leak protection
  • The discharge baffle shall have a rolled bead for added strength, an integral conduit chase shall be provided through the curb cap and into the motor compartment to facilitate wiring connections
  • The motor shall be enclosed in a weather-tight compartment, separated from the exhaust airstream
  • Unit shall bear an engraved aluminum nameplate
  • Wheel shall be centrifugal backward inclined, constructed of 100% aluminum, including a precision machined cast aluminum hub
  • An aerodynamic aluminum inlet cone shall be provided for maximum performance and efficiency
  • Motor shall be NEMA design B with class B insulation rated for continuous-duty and furnished at the specified voltage, phase and enclosure
  • Motor shall be an electronically commutated motor rated for continuous-duty and furnished either with internally-mounted potentiometer speed controller or with leads for connection to 0 - 10 VDC external controller
  • Catalog https://assets.unilogcorp.com/267/ITEM/DOC/COOK_135C13D_Catalog.pdf
